OpenSearch Transform Job: The Case of the Silent Failure and the Ghost Key

Debugging OpenSearch Transform jobs can feel like searching for a needle in a haystack, especially when the error messages are generic. This post chronicles a recent debugging journey, highlighting common pitfalls and the ultimate solution to a persistently failing transform job.

The Problem: Summarizing XRootD Stash Data

Our goal was straightforward: aggregate XRootD stash access logs (xrd-stash*) into a daily summary index (osdf-summary-{year}). This involved grouping by several file path components, server details, and user domains, then calculating sums, averages, and counts of metrics like filesize, read, and write.

Here is a snippet of the initial (problematic) transform configuration:

{
  "transform": {
    "transform_id": "osdf-summary-2022",
    "description": "OSDF summary transform for year 2022",
    "source_index": "xrd-stash*",
    "target_index": "osdf-summary-2022",
    "page_size": 1000,
    "groups": [
      {
        "date_histogram": {
          "source_field": "@timestamp",
          "target_field": "@timestamp",
          "calendar_interval": "1d"
        }
      },
      {
        "terms": {
          "source_field": "dirname1.keyword",
          "target_field": "dirname1"
        }
      }
    ],
    "aggregations": {
      "filesize_sum": { "sum": { "field": "filesize" } },
      "filesize_avg": { "avg": { "field": "filesize" } }
    }
  }
}

The Symptoms: Generic Errors and Timeouts

The transform job kept failing with a rather unhelpful message in its metadata:

{
  "status": "failed",
  "failure_reason": "Failed to index the documents",
  "stats": {
    "pages_processed": 96,
    "documents_processed": 89737708,
    "documents_indexed": 96000,
    "index_time_in_millis": 44733,
    "search_time_in_millis": 1715612
  }
}

Notice the high search_time_in_millis compared to index_time_in_millis. This was a critical clue that the aggregation phase was struggling.

Further attempts to debug with _explain or custom composite aggregation queries often resulted in:

• 502 Bad Gateway / timed_out: The query was too resource-intensive for the cluster to handle.
• illegal_argument_exception: Missing value for [after.date_histogram]: A mismatch in how the after_key was structured versus the sources in the composite aggregation.
• illegal_argument_exception: Invalid value for [after.site], expected comparable, got [null]: The transform was getting stuck on null values within its grouping keys.

The Debugging Journey and Discoveries

Through a series of focused queries and iterative refinements, we uncovered several interconnected issues.

1. Composite Aggregation Challenges and the “Ghost Key”

Our composite aggregation debugging queries kept failing. This was traced to:

• Syntax mismatches: names in the after key must exactly match the names defined in sources (for example, @timestamp must match @timestamp).
• null values in after_key: terms aggregations can fail when after_key includes null, unless handled explicitly.

Then came the key finding: a direct search for documents matching the transform’s after_key yielded zero results. The transform was trying to resume from a state that no longer existed in source data.

2. The Real Culprit: Unparsed “Garbage” Data

An inverse query (documents missing expected fields) revealed records like:

{
  "_index": "xrd-stash-ilm-000037.reindexed",
  "_id": "cAqUoH4BOTrVvgqCSyKq",
  "_source": {
    "message": "GET / HTTP/1.1\n",
    "@timestamp": "2022-01-28T12:06:20.222Z",
    "host": "ec2-3-110-169-111.ap-south-1.compute.amazonaws.amazonaws.com",
    "tags": ["_grokparsefailure"]
  }
}

These were logs that failed parsing and were actually web traffic hitting the server, not XRootD stash operations. They lacked key transform fields like logical_dirname, filesize, and server.

When the transform encountered enough of these records, grouping keys became null. Combined with malformed or very long field values, the composite aggregation became unstable and hit timeouts.

3. Precision for PetaByte-Scale Data

Not a crash cause, but still important: float is not precise enough for large sums at petabyte scale.

Solution: use double for sums/averages and long for counts.

The Ultimate Solution: Resilience and Precision

The final, robust fix used multiple changes together.

1. Stop and Delete Stale State

Stop the transform and delete the target index to clear bad transform/index state.

POST _plugins/_transform/osdf-summary-2022/_stop
DELETE osdf-summary-2022

2. Recreate Index with Explicit High-Precision Mappings

PUT osdf-summary-2022
{
  "mappings": {
    "properties": {
      "@timestamp": { "type": "date" },
      "dirname1": { "type": "keyword" },
      "logical_dirname": { "type": "keyword" },
      "filesize_sum": { "type": "double" },
      "filesize_avg": { "type": "double" },
      "filesize_count": { "type": "long" },
      "doc_count": { "type": "long" }
    }
  }
}

3. Add Intelligent Filtering in data_selection_query

• Exclude _grokparsefailure events.
• Require existence of critical grouping fields.
• Add script guards against empty or oversized keyword values.

"data_selection_query": {
  "bool": {
    "must": [
      {
        "range": {
          "@timestamp": {
            "gte": f"{year}-01-01T00:00:00Z",
            "lt": f"{year + 1}-01-01T00:00:00Z"
          }
        }
      }
    ],
    "must_not": [
      { "term": { "tags": "_grokparsefailure" } }
    ],
    "filter": [
      { "exists": { "field": "logical_dirname.keyword" } },
      {
        "script": {
          "script": "doc['logical_dirname.keyword'].size() > 0 && doc['logical_dirname.keyword'].value.length() < 1000"
        }
      }
    ]
  }
}

4. Reduce page_size

Lowering page_size from 1000 to 50 significantly reduced memory pressure per composite aggregation page and helped avoid 502 Bad Gateway failures.

5. Restart the Transform

After recreating the index and updating the transform definition, restart the job.

Conclusion

By combining explicit mappings, stronger filtering, smaller pagination, and a reset of stale transform state, the transform ran reliably and produced accurate summaries without repeated failure loops.

This debugging story reinforced a key lesson: robust pipelines are not just about handling valid data, but actively excluding invalid or malformed records before they poison downstream aggregation logic.
